What are the Qualities of Hot Sale 316L Stainless Steel Plate

Posted:3/13/2017 11:25:16 PM



Type 316L stainless steel is an extra-low carbon version of the 316 steel alloy. The differences between a 316L and a 316 straight grade are two-fold both in chemistry and mechanical properties.

Application of 316L Stainless Steel

Grade 316L is more resistant to carbide precipitation and can be used in the above temperature range, Such as Pharmaceuticals, Marine applications, Architectural applications, Medical implants.

Type 316 and 316L Stainless Steel Composition:


Element

Type 316 (%)

Type 316L (%)

Carbon

0.08 max.

0.03 max.

Manganese

2.00 max.

2.00 max.

Phosphorus

0.045 max.

0.045 max.

Sulfur

0.03 max.

0.03 max.

Silicon

0.75 max.

0.75 max.

Chromium

16.00-18.00

16.00-18.00

Nickel

10.00-14.00

10.00-14.00

Molybdenum

2.00-3.00

2.00-3.00

Nitrogen

0.10 max.

0.10 max.

Iron

Balance

Balance

Mechanical properties of 316L stainless steels


Grade

Tensile Str
(MPa) min

Yield Str
0.2% Proof
(MPa) min

Elong
(% in 50mm) min

Hardness

Rockwell B (HR B) max

Brinell (HB) max

316L

485

170

40

95

217

Physical Properties of Type 316 Steels

1, Density: 0.799g/cm3
2, Electrical resistivity: 74 microhm-cm (20C)
3, Specific Heat: 0.50 kJ/kg-K (0-100°C)
4, Thermal conductivity: 16.2 W/m-k (100°C)
5, Modulus of Elasticity (MPa): 193 x 103 in tension
6, Melting Range: 2500-2550°F (1371-1399°C)

Shanghai Katalor Enterprises Co., Ltd is specialized in supplying 316L Stainless Steel Plate. Besides that, Shanghai Katalor Enterprises Co., Ltd is also a manufacture, so we could promise the delivery time and the competitive price compared with other company. We sincerely hope new and regular customers come to visit our mill and inquiry316L Stainless Steel from Katalor.
