Sa204 grade B steel,SA-204 Gr.C Mo-alloy steel plates

Posted:2014-11-30 21:07:01

sa204 grade b steel is a kind of pressure vessel steel, it under ASME standard. Obviously, SA204 this property is based on it's Mo composition. ASME SA-204/SA-204M SA204 has three grades or levels-- Grade A/B/C.As a pressure vessel steel, sa204 grade b steel minimum yield strength is 275 Mpa, its tensile strength is 485-620 Mpa. It is widely used in fabricators serving industry, especially in the oil, gas and chemical supply markets.

sa204 grade b steel size we mainly supply: T*W*L: 6-300mm*1500-4020mm*3000-18000mm

sa204 grade b steel chemical composition

sa204 grade b steel chemical composition

Grade

The Element Max (%)

C

Si

Mn

P

S

sa204 grade b

0.20-0.27

0.13-0.45

0.90-0.98

0.035

0.035

sa204 grade b steel mechanical property

Grade

sa204 grade b steel mechanical property

Tensile Strength

(MPa)

Yield Strength

(MPa)

% Elongation in 2 in.(50mm) min

ImpactingTest Temperature

(°C)

sa204 grade b

485

275

21

-20,40,-60

Equivalent steel grade of SA204 Gr B

Equivalent steel grade of SA204 Gr B

Europe

Belgium

Germany

France

Italy

Sweden

India

Japan

15 CD 4.05

If you are interested in some items of our steel materials or need consult for the any technical requirements,please contact us freely by email or chat with our liveperson!
