S235J2 steel plate, S235j2 Steel Plate Suppliers and Manufacturers ,S235J2 steel sheet
S235J2 steel plate, S235j2 Steel Plate Suppliers and Manufacturers ,S235J2 steel sheet
KeyWords: S235j2 Steel Plate, S235j2 Steel, S235j2 Steel Plate suppliers,S235j2 Steel Plate Manufacturers ,S235J2 steel sheet
EN 10025 S235J2 steel plate, S235J2 steel plate, under EN10025 standard, we can regard S235J2 steel plate as Carbon structural steel.We also call S235J2 steel as common structural steel. The equal material of S235J2 steel are : DIN-ST37-2, JIS-SS400, ASTM - 36 and ASTM - A283GRC. The standard of S235J2 is EN 10025. S235J2 steel plate is one mainly of Carbon structural steel, S235J2 steel plate would be used to built containers which can bear low temperature sea water.
S235J2 steel Chemical composition
| Grade | C % | Si % | Mn % | P % | S % | N % | Cu % |
| S235j2 | 0.190 | - | 1.500 | 0.035 | 0.035 | - | 0.060 |
S235J2 steel mechanical properties
| Grade | Thickness(mm) | Min Yield (Mpa) | Tensile(MPa) | Elongation(%) | Min Impact Energy | |
| S235j2 | 8mm-100mm | 215Map-235Mpa | 360-510Mpa | 21-26% | -20 | 27J |
| 101mm-200mm | 195Mpa | 340-500Mpa | 22% | -20 | 27J | |
| 201mm-400mm | 175Mpa | … | 21% | -20 | 27J | |
| The min impact energy is longitudinal energy | ||||||
Technical Requirements & Additional Services:
♦ Low temperature impacting test
♦ Rolling under standard NACE MR-0175
♦ Ultrasonic test under EN 10160,ASTM A435,A577,A578
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user’s demands
Katalor Enterprises focuses on steel business both in international and domestic market and caters to international steel market. we will give you the lowest price and best support to make your esteemed company to be the top class steel supplier and distributor.So just feel free to contact us if you have any question about us or S235j2 Steel Plate!
