ABS DH32 shipbuilding steel

Posted:11/4/2015 4:01:54 AM

ABS Grade DH32,ABS Grade DH32 shipbuilding steel plate,ABS DH32 plate,ABS Grade DH32 ship plate,ABS Grade DH32 marine steel plate are mainly used to build vessels which are sailing in low temperature oceans.we specialized in supplying ABS high strength steel plate in ABS Grade DH32.

DH32 products include steel shipbuilding plate, fabricated steel sections and floor plate for decking. We can also supply bulb flats for plate stiffening, structural steel angles and inverted angles. Main application of ABS Grade DH32 shipbuilding steel plate is building decks of ships,vessels and boats,other normal repairing works in shipyards.

AB/DH32 high Strength Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

AB/DH32

0.18

0.1-0.50

0.90-1.6

0.035

0.035

0.015

-

Nb

V

Ti

Cu

Cr

Ni

Mo

0.02-0.05

0.05-0.10

0.02

0.35

0.2

0.4

0.08

Crack Sensitivity:  Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent:  Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】

AB/DH32 high strength property

Grade



Mechanical Property

Charpy V Impact Test

Thickness

Yield

Tensile

Elongation

Degree

Energy 1

Energy 2

AB/DH32

mm

Min Mpa

Mpa

Min  %

-20

J

J

t≤50

315

440-590

22%

22

31

50<t≤70

315

440-590

22%

26

38

70<t≤100

315

440-590

22%

31

46

Note: Energy 1 is transverse impact test, Energy 2 is longitudinal

 If you need  more technology  support and lowest price for cooperation about ABS Grade DH32 shipbuilding steel plate,just feel free to contact us by email or chat uw our liveperson,we will give you the best service for you!
