Top Quality ASTM A572 Grade 65 Steel Material

Posted:2016/10/12 4:55:42

Top Quality ASTM A572 Grade 65 Steel Material

ASTM A572/A572M is Standard Specification for High-Strength Low-Alloy Columbium-Vanadium Structural Steel. A 572 Gr.65 steel plate are intended for riveted or bolted construction of bridges or for riveted , bolted, or welded construction in other applications.

Chemical composition % of the Product analysisof grade A572 Grade65.

A572 Grade 65 Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

V

Ni

Co

A572 Grade 65

0.23

0.4

1.35

0.04

0.05

0.06

0.015

0.05

Mechanical properties of ASTM A572 Grade 65 Steel

Grade

Thickness(mm)

Min Yield (Mpa)

Tensile(MPa)

Elongation(%)

A572 Grade 65

8mm-50mm

450Mpa

550Mpa

17%

50mm-200mm

450Mpa

550Mpa

15%

The min impact energy is longitudinal energy

Other steel category:

Boiler steel plate

Marine steel

Corten steel plate

Stainless steel plate

HSLA steel plate

API Pipeline steel

Spring steel

Cold rolled steel

High Yield Steel

Section steel

Grade 65 Steel Specification:

steel Grade :A572 Grade 65
Thickness 8mm-200mm,
Width: 1500-4020mm,
Length: 3000-27000mm
We can supply any size based on customer's requirements
Standard: ASTM A572 Standard Specification for High-Strength Low-Alloy Columbium-Vanadium Structural Steel
Approval By Third Party: ABS, DNV, GL, CCS, LR , RINA, KR, TUV, CE

As a very long history company, Shanghai Katalor Enterpriseshad enough experience about the quality, price for these goods in China Market. we are a professional A 572 Gr.65 steel plate stockist and supplier. We can supply different product type and grades of . If you want to get the price, please do not hesitate tocontact us.
