P420M steel plate in stock price
P420M steel plate is a kind of steel for boiler and pressure vessel.P420M steel plates has a minimum yield strength of 390-420 MPa with good weldability.
P420M chemical composition（%）:
| Grade |
P420M max % |
element |
P420M max % |
|
C |
0.16 |
Mo |
0.20 |
|
Si |
0.50 |
Nb |
00.05 |
|
Mn |
1.70 |
Ni |
0.50 |
|
P |
0.025 |
TI |
0.05 |
|
S |
0.020 |
Vi |
0.10 |
|
AL |
0.020 min |
|
|
|
N |
0.020 |
|
|
P420M steel mechanical property:
| Grade |
Type |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Impact Energy |
|
(mm) |
MPa (min) |
MPa |
% (min) |
(KV J) (min) |
||
|
-20 degree |
||||||
|
P420M |
Normalized |
≤ 16 |
420 |
500-660 |
19 |
27 |
|
16> to ≤40 |
400 |
|||||
|
40> to ≤63 |
390 |
|||||
P420M Application:
P420M steel plate has good toughness and tensile strength, so it is widely used to make equipments and components of reactor, heat exchanger, spherical tank, oil gas tank, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefied petroleum gas cylinder, high pressure water pipes of hydropower station and used in the industries of petroleum, chemistry, power station and boile.
P420M Size range:
Thickness: 6MM to 300MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm
P420M Payment Term :
T/T or L/C At sight
P420M Third Party Inspection:
ABS, DNV, BV, GL, CCS, LR, RINA, KR, NK, CE, SGS, IKE, IEI or other quality department.
P420M steel Extra Service:
Pretreatment (Shot Blasting, Sand Blast, Painting and Galvanized), Cutting Parts, Sample Service, Third Party inspection, UT Test and Size inspection.
P420M Heat Treatment:
As hot rolled, normalized, stress relieving annealing
