EN10025-3 S275N Hot Rolled Structural Steel Factory Price
S275N is a kind weld able fine grain structural steel which shall be under normalized or normalized rolled delivery condition. The steel grade is under EN10025- 3 standard, equivalent to DIN StE285, with a minimum impact energy of 20J at temperatures not lower than -20 degree.
Mechanical property for S275N Structural steel:
Thickness (mm) |
||||||||
|
S275N |
≤ 16 |
> 16 ≤ 40 |
> 40 ≤ 63 |
> 63 ≤ 80 |
> 80 ≤ 100 |
> 100 ≤ 150 |
> 150 ≤ 200 |
> 200 |
|
Yield strength (≥Mpa) |
275 |
265 |
255 |
245 |
235 |
225 |
215 |
205 |
|
|
≤ 100 |
> 100 ≤ 200 |
> 200 |
|||||
|
Tensile strength (Mpa) |
370-510 |
350-480 |
350-480 |
|||||
Chemical composition for S275N Structural steel (Heat Analysis Max%)
Main chemical elements composition of S275N |
||||||
|
C |
Si |
Mn |
P |
S |
Nb |
V |
|
0.18 |
0.40 |
0.50-1.50 |
0.030 |
0.025 |
0.05 |
0.05 |
|
Al(total) |
Ti |
Cr |
Ni |
Mo |
Cu |
N |
|
≥0.02 |
0.05 |
0.30 |
0.30 |
0.10 |
0.55 |
0.015 |
S275N Hot Rolled Structural Steel Specification
Steel Standard: EN 10025-3
Rolling Type: Structural steel plate, low alloy steel plate
Thickness: 6mm-500mm
Width: 1500mm-4000mm
Length: 3000mm-12000mm
We can supply any size based on customer's requirements.
EN10025-3 S275N Technical Requirements Additional Services:
First, Low temperature impacting test
Second, Rolling under standard NACE MR-0175 (HIC+SSCC)
Third, Ultrasonic test under EN 10160,ASTM A435,A577,A578
Fourth, Issued Original Mill test certificate under EN 10204 FORMAT 3.1/3.2
Fifth, shot blasting and Painting, Cutting and welding as per end user’s demands
EN10025-3 S275N application can be offered by KATALOR in China. KATALOR is a professional S275N Hot Rolled Structural Steel supplier and manufacturer, if you need EN10025-3 S275N Hot Rolled Structural Steel price and specification, please feel freely to contact us by email [email protected].
