EN 10028 P355GH pressure-vessel steels Related grade

Posted:8/1/2016 2:32:29 AM





Widely used throughout the petrochemical industry, P355GH is a pressure vessel steel grade as specified under the Euro Norm standard (EN10028) which has superseded British Standard and DIN standard equivalents.

This normalized steel is used worldwide by fabricators of welded pressure vessels, industrial boilers and heat exchangers and is engineered to work well in elevated temperature service.

Chemical Composition of EN 10028 P355GH:

Element

% by mass

Element

% by mass

Carbon (C)

0.10 to 0.22

Silicon (Si)

≤0.60

Manganese (Mn)

1.10 to 1.70

Phosphorous (P) (max)

0.025

Sulphur (S) (max)

0.015

Aluminium (Al)

≤0.020

Nitrogen (N)

≤0.012

Chromium (Cr)

≤0.30

Copper (Cu)

≤0.30

Molybdenum (Mo)

≤0.08

Niobium (Nb)

≤0.020

Nickel (Ni)

≤0.30

Titanium (Ti) (max)

0.03

Vanadium (Vi)

≤0.02



Mechanical Properties of EN 10028 P355GH:

Grade

Type

Thickness
(mm)

Yield Strength
MPa (min)

Tensile Strength
MPa

Elongation
% (min)

Impact Energy
(KV J) (min)

-20°

+20°

P355GH

Normalized

≤ 16
16> to ≤40
40> to ≤60
60> to ≤100
100> to ≤150
150> to ≤250

355
345
335
315
295
280

510 to 650
510 to 650
460 to 580
490 to 630
480 to 630
470 to 630

20
20
20
20
20
20

27
27
27
27
27
27

34
34
34
34
34
34

40
40
40
40
40
40
