ASTM A572-50 carbon-low alloy steel applications

Posted:2016/12/4 22:04:03

ASTM A572-50 carbon-low alloy steel applications



ASTM A572-50 is a carbon-low alloy steel with a low weight, high tensile strength and yield strength, good ductility and easy to weld. ASTM A572-50 contains a variety of alloying elements so that it has a better corrosion resistance. ASTM A572-50 can be used for bridge plate, gussets, floor, structural steel and other supporting materials.



ASTM A572-50 Physical properties:

Steel Type

High Strength/Low Alloy

ASTM Designation

A572 Grade 50

Common PGI Inventory

0.25” – 5.00” inquire for thicker plate

Minimum Yield Stress (ksi)

50

Average Tensile Strength (ksi)

65

Elongation at Breakage

18%

Approximate Hardness (Rc)

na

Approximate Hardness (Rb)

74

Brinell Hardness

135

Machinability

0.72



ASTM A572-50 Chemical composition:

% Carbon (C)

0.230

% Manganese (Mn)

1.35

% Niobium (Nb)

0.005-0.050

% Phosphorus (P)

0.040

% Silicon (Si)

0.150-0.400

% Sulfur (S)

0.050

% Vanadium (V)

0.010 – 0.050



ASTM A572-50 Application:
ASTM A572-50 is widely used in many applications, like: steel mills produce channel and heavy beams with Grade 50. It is commonly used in structural applications, heavy construction equipment, building structures, heavy duty anchoring systems, truck frames, poles, liners, conveyors, boom sections, structural steel shapes, and applications that require high strength per weight ratio.
