ASTM A283Grade C Steel Plate Unique Use

Posted:10/8/2016 4:49:42 AM

ASTM A283Grade C Steel Plate Unique Use

ASTM A283 Grade C Steel Plate is a kind of common carbon structure steel. The tensile of ASTM A283 GR.C is low or mid-low.A283 steel grade covers four grades in A283 Grade a, A283 Grade B, A283 Grade C, and A283 Grade D of carbon steel plates of structural quality for general application.

ASTM A283 Steel Plate Chemical Properties



Grade A

Grade B

Grade C

Grade D

Carbon, max

0.14

0.17

0.24

0.27

Manganese, max

0.90

0.90

0.90

0.90

Phosphorus, max

0.035

0.035

0.035

0.035

Sulphur, max

0.04

0.04

0.04

0.04

Silicon
Plates 1 1/2 in and under, max
Plates over 1 1/2 in



0.40
0.15-0.40



0.40
0.15-0.40



0.40
0.15-0.40



0.40
0.15-0.40

Copper min % when copper steel is specified

0.20

0.20

0.20

0.20

ASTM A283 Steel Mechanical Properties



Grade A

Grade B

Grade C

Grade D

Tensile Strength:

45,000 -60,000 psi
[310 - 415 MPa]

50,000 -65,000 psi
[345 - 450 MPa]

55,000 75,000 psi
[380 - 515 MPa]

60,000 -80,000 psi
[415 - 550 MPa]

Min. Yield Point:

24,000psi
[165 MPa]

27,000psi
[185 MPa]

30,000psi
[205 MPa]

33,000psi
[230 MPa]

Elongation in 8":

27% min

25% min

22% min

20% min

Elongation in 2":

38% min

28% min

25% min

23% min

ASTM A283Grade C Steel Plate Specification

Material:ASTM A283 GR.C
Standard:ASTM
Thickness: 6-80mm,
Width: 1500-3000mm,
Length: 6000-12000mm
We can supply any size based on customer's requirements.

As a very long history company, Shanghai Katalor Enterpriseshad enough experience about the quality, price for these goods in China Market. we are a professional ASTM A283Grade C stockist and supplier. We can supply different product type and grades of ASTM A283 Steel Plate. If you want to get the price, please do not hesitate tocontact us.
