ASME SA387 GR.11 CL.1 Chemical Content
ASME SA387 GR.11 CL.1 material is a kind of alloy steel plates that are formed with chromium- molybdenum content. In addition to it includes other content such as nickel, tungsten, columbium, and aluminum. These additional elements offer superior resistance to corrosion and high-temperature tensile strength. These ASME SA387 GR.11 CL.1 plates are ideal in that circumstance where hot liquids and gases are carried out frequently. The plates have a superior capability to tolerate high temperatures in tough circumstances. The ASME SA387 GR.11 CL.1 steel products are basically annealed in various situations that enable superior strength. Thus the addition of chromium content ensures superior resistance to oxidation and oxygen.
ASME SA387 GR.11 CL.1 Chemical Analysis, %
Grade |
C |
Mn |
Si |
P max |
S |
Cr |
Mo |
SA387 Grade 11 Class1 |
0.04-0.17 |
0.35-0.73 |
0.44-0.86 |
0.035 |
0.035 |
0.94-1.56 |
0.40-0.70 |
ASME SA387 GR.11 CL.1 Steel Features
These SA 387 GR.11 CL.1 PLATES are often recognized as weldable carbon pressure vessel grade plate that generally utilized at elevated temperature. Furthermore, the plates offer superior excellent resistance to stress corrosion cracking, heat, and various corrosive media. The SA387 GR.11 CL.1 plates have outstanding durability, toughness, and hardness. Thus these are easily machined and fabricated.
As with all ASME and ASTM pressure vessel steels, Chrome Moly to SA387 and A387 is produced in conformity to SA20 / A20 which outlines the testing and retesting methods and procedures, permissible variations in dimensions and weight, quality and repair of defects, marking, loading, and ordering information.
Quality Checks ad Inspection
Strictly quality checks and inspections procedures are done in order to determine the quality of the SA387 GR.11 CL.1 steel plate product. The test is like a drop weight test, high-temperature tension test, magnetic particle examination, additional tension test, Charpy test, ultrasonic test, vacuum treatment. Other more tests are like tensile strength test, chemical analysis, PMI test, flaring test and IGC test. All such test is performed under the guidance of our professional experts to offer an error-free product to the patrons.
We provide approved test certificates to the buyer according to the EN 10204 3.1 or 3.2l. Other more certificates are like raw material test reports and 100% radiography. Welcome to contact us if you interested in SA387 GR.11 CL.1 plates.
