1.0045 s355jr steel Plate Processing

Posted:8/18/2016 5:16:56 AM

1.0045 s355jr steel Plate Processing

S355JR is a low carbon, high tensile strength structural steel which can be readily welded to other weldable steel. With its low carbon equivalent, it possesses good  cold-forming properties. 1.0045 s355jr steel Plate is mainly used in Structural application in freight cars, transmission towers, dump trucks, cranes, trailers and so on.

S355JR Chemical Composition(max%):

Grade

C%

Si%

Mn%

P%

S%

N%

Cu%

S355JR

0.27

0.60

1.70

0.035

0.035

0.012

0.60

S355JR Mechanical Properties.

Grade

Thickness(mm)

MinYield(Mpa)

Tensile(Mpa)

Elongation(%)

MinImpactEnergy

S355JR

8mm-100mm

315Mpa-355Mpa

450-630Mpa

18-20%

20

27J

101mm-200mm

285-295Mpa

450-600Mpa

18%

20

27J

201mm-400mm

275Mpa

-

17%

20

27J

Theminimpactenergyislongitudinalenergy

Equivalent grades of grade S355JR (1.0045)

USA
-

Germany
DIN,WNr

Japan
JIS

France
AFNOR

England
BS

Canada
HG

European old
EN

Italy
UNI

Belgium
NBN

Spain
UNE

China
GB

Sweden
SS

Inter
ISO

Portugal
NP

India
IS

A572

A678Gr.A

SSGrade50

St52-3

SM490A

SS490

E36-2

50B

350W

350WT

Fe510B

Fe510B

AE355B

AE355B

Q345B

Q345C

2132-01

E355C

Fe510B

FE510-B

IS961

1.0045 s355jr steel Plate Welding performance

Our production completely according to the 1.0045 standards to meet the 1.0045 Welding performance, can also according to the customer request, to meet the requirements of customers of 1.0045 Welding performance.
1.0045 s355jr steel Plate Delivery Condition:
Smelting: EAF+LF+VD (+ESR)
Making: Hot rolled, Cold rolled, Forged, Cold Drawn
Heat Treatment: Untreated, Annealing, N+T, Q+T
Surface: Black, Peeled, Turned, Milled, Grinded, Polished

We have our own processing factory and the pre- treatment factory, Surface pretreatment line technical parameters on steel plates and profile steel. And we can also make the customers enjoy our other pre-treatment services, like cutting, welding, drilling holes, galvanizing by the lowest cost price. We are a professional1.0045 s355jr steel Plate exporter and Stockist in china. Any need in 1.0045 s355jr, please feel free to contact us by email or calling to us by email imfo@Katalor.com.
